50-Series Push Pogo Probe Holder

PPH-50

1.50 USD
Qty
Price
1
$1.50 ea.
2+
$1.25 ea.
25+
$1.19 ea.
100+
$1.10 ea.

This little devices allow you to simply and easily install and replace existing 50-series pogo pins


Description [Hide]

This pogo pin holder allows PP-50 series of pogo pins to press fit into it in order to quickly replace them if needed. This holder accepts the PP1-50 & PP2-50 pogo pins.

Features

  • Head type: N/A
  • Dimensions: 17.5 x 0.97 x 0.97mm
  • Recommended min-center: 1.27mm
  • Spring force: 80gms
  • Current rating: 3A
  • Contact resistance: 50milliohms
  • Full travel: 2.5mm
  • Mounting hole size: 0.91-0.95mm
