Friday New Product: Grove, Charger, Strobe LEDs

May 1, 2015

Posted By Yana

We are going to continue with some nice Grove products and mix it up with other bits and pieces:

Grove – Moisture Sensor
$6.36

This simple Grove moisture sensor is ideal for measuring soil dampness.
Grove – I2C Touch Sensor
$19.38
This advanced Grove sensor breaks out into 4 touch sensor pads for finger proximity detection.
Grove – Light Sensor
$3.78

Inexpensive and well designed, it’s handy for general light intensity measurements.
Grove – Water Sensor
$3.78
A simple but effective Grove water sensor. Expose the electrodes to a drop of water, and the signal drops very low. Can be used with both analog and digital ports.
SparkFun LiPo Charger Basic – Mini-USB
$9.54

Simple, no-brainer method to charge up a single cell Li-Ion / LiPoly battery.
5mm RGB strobe LEDs
$0.80

Quick and simple way to add cycling Red/Green/Blue LEDs to a project.
44mm Piezo Speaker
$3.00

For making a LOUD beep, this piezo suits your need. Comes mounted in a plastic case with mounting tabs.

The Arc Reactor Project

April 24, 2015

Posted By Yana

We needed all our superpowers for the Calgary Comic & Entertainment Expo this past weekend, so we decided to create our version of Arc Reactor for the team to wear at the show in order to augment the intelligence and add superhuman-level multitasking and learning capabilities (imagination is key at the Comic Expo).

Not happy with just a blinky light, we added connectivity to our setup, which consists of:

  1. The arc reactor pendants. These are worn around the neck and under the shirts, shining through the light fabric, each containing a Synapse mesh-networking radio and control electronics.
  2. The activation box. This contains a Synapse module in an acrylic box. The button initiates a “synchronize to THIS color” signal to all modules on the network.



The pendant case is consists of a 3D printed housing made in-house on our Kossel (we’ll be selling units shortly), with a laser engraved semi translucent acrylic diffuser on top.

A static Arc Reactor just isn’t very visually appealing, so we spiced it up with a flicker, with a “power pulse” on color-mode change.

Component Layout:

The Activation Box

Parts List:

1 x Synapse-to-FTDI Adapter Kit
1 x Synapse RF200P81
1 x Concave Button  (Arcade button)
1 x 5 x AA Holder
1 x DPDT Slide Switch
1 x 330 Ohm Resistor

Principles of Operation:

The box features only 2 input, the main power switch, and the big red button. The button pulls the Synapse module Pin 3 high, which then causes it to transmit a single ascii character (1 through 8 ) to all the receivers.

Synapse modules have an embedded python interpreter, which is called “SNAPpy”. We use this to create “Remote Procedure Calls” (“RPC”) that are routines we can call either local or wirelessly from up the network. The script in the transmitter has a global variable which increments each time the button is pressed, and is multicast out to all the Arc Reactor receivers. The auto-mesh-networking of the Synapse modules means that these calls will be aut0-relayed down the chain to all nodes in the network, even if the Activation box is out of range from the furthest Arc Reactor. With an outdoor range of nearly a kilometer, we didn’t any signalling problems inside the event hall.



The Arc Reactor Modules

Parts List:

1 x Adafruit Neopixel Ring 24
1 x Synapse RF200P81
1 x Solarbotics Synapse Breakout Board Kit
1 x Arduino Pro Mini
1 x Flora RGB Neo Pixel v2
1 x Polymer Lithium Ion Battery
1 x Vibrating Disk Motor
1 x NPN Transistor
1 x JST-PH-2.0 2 Pin Connector Plug w/Wire
1 x 330 Ohm Resistor

Principles of Operation:

The Synapse radio in each Arc Reactor takes the received value and turns it into binary number output on 3 pins.  (1 = 001, 8=111). Time was tight, and we went with a robust, simple method to send this information to the Arduino controlling the LEDs.

The Arduino Pro Mini monitors these pins, and changes the color palette as required. We selected the 24 element Adafruit Neopixel ring to provide illumination connected to the Pro Mini Pin 2.  The awesome FastLED.io Library was used to communicate the data to the pixels.

Initial experiments proved power consumption to be a problem. Rather than powering all LEDs to some level of power, we rewrote the code to turn on only 4 adjacent segments at a time, with the first element at 100% power, the second at 50%, the third at 25%, and the fourth at 12%. This created a really nice flicker effect when rapidly cycled through the ring.



Thoughts, and Conclusions

At one point during the first day of the event, we discussed how funny it would be if we could feel when the reactor is activated, so we could all “JUMP” in unison when somebody hit the switch. A quick on-the-site hack later with a transistor and vibrating disk motor, with a quick code-update (on the fly through the wireless mesh!), we were all buzzing.  Unfortunately, when kids and evil co-workers discovered how nasty it felt to have simulated mild heart palpitations available on-demand, we had to snip the wires on most of the reactors. Haptic feedback, especially mid-chest, can be disturbing.

The technique we outlined here was used in a very similar way on the movie “Tron: Legacy” where similar hardware was used to control the costumes. We found it a very quick and robust way to add group-control to our project.

The Arc Reactor itself was well received by the Cosplay community in attendance. Although not for sale at the time, we’ve been strongly encouraged to make the visual aspect of the Arc Reactor available as a kit. Stay tuned…



Code:

Arc Reactor Button.py – Synapse code for the Button

Arc Reactor Pendant Synapse code.py – Synapse code for the Pendant

Arc_Reactor_Pendant.ino – Arduino code for the Pendant

Friday New Product: Grove and More

Posted By Yana

Since we haven’t announced new products for a while, we are bringing you a multitude of items, including Grove-compatibles, SD cards, and a lonesome piezo speaker:

Grove – Encoder
$6.36

This grove unit is a simple way to add a rotation input device to your project.
Grove – PIR Motion Sensor
$11.52
The Grove PIR sensor is specifically tuned to detect the moving heat signatures of human bodies.
Grove – Tilt Switch
$2.46

Super simple – it’s a ball in a tube that plugs into the Grove system to detect tilt.
Grove – LED Bar
$5.04
Another nice visual indicator for the Grove system, with a 10 segment display.
4GB MicroSD Card with Adapter
$9.60
Name-brand memory cards are a safe bet for getting a quality memory card.
8GB MicroSD Card with Adapter
$13.20
Name-brand memory cards are a safe bet for getting a quality memory card.
SparkFun Venus GPS with SMA Connector
$59.94
GPS units continue to improve, and the SparkFun Venus is one of the smallest & versatile available.
44mm Piezo Speaker
$3.00
For making a LOUD beep, this piezo suits your need. Comes mounted in a plastic case with mounting tabs.
