ATtiny85

28904

2.85 USD
Qty
Price
1
$2.85 ea.

Hey look, an Atmel chip! Amazing! Well, it is a nice improvement on the popular ATtiny45 in that it now offers 8kB of programmable Flash.


Description [Hide]

Here's what the geniuses at AVRFreaks have to say about it!

This is a nice upgrade to the very popular ATtiny45 microcontroller, bringing up the Flash to 8kB! The ATtiny85 features: 8K Bytes of In-System Self-Programmable Flash, 512 Bytes In-System Programmable EEPROM, 512 Bytes Internal SRAM. Two 8-bit timer/counters with PWM and prescaler, 10-bit ADC, I2C Interface and debugWIRE for on-chip-debug. Up to 20 MIPS throughput at 20 MHz. 2.7 - 5.5 V operation. Also available in 1.8 V version (ATtiny85V). Smaller Flash versions available -> 4KB version: ATtiny45 2KB version: ATtiny25



Program Memory Size: 8KB
RAM Size: 512B
Number of I /O: 6
Package / Case: 8-DIP
Speed: 20MHz
Controller Series: ATtiny
Oscillator Type: Internal
Program Memory Type: FLASH
EEPROM Size: 512B
Core Processor: AVR
Data Converters: A/D 4 (10-bit resolution)
Core Size: 8-Bit
Operating Temperature: -40°C ~ 85°C
Connectivity: USI
Peripherals: Brown-out Detect/Reset, POR, PWM, WDT
Voltage - Supply (Vcc/Vdd): 2.7 V ~ 5.5 V

Cross-relation

  • pin and feature compatible with tiny25, more memory.
  • pin and feature compatible with tiny45, more memory.

Overview features

FlashEEPROMSRAMSpeedVolts
8kB 512B 512B 0 - 20MHz 2.7 - 5.5V



<
