Phidget InterfaceKit 0/0/8

33165

85.71 USD
Qty
Price
1
$85.71 ea.

The Phidgets 0/0/8 controls 8 relays from the convenience of your connected PC


Description [Hide]

The PhidgetInterfaceKit 0/0/8 provides Small Signal Relays with 8 Relay Outputs, rated at 250VAC, or 2 Amps, for a maximum of 65 Watts. It is typically used for switching small signals, as opposed to high current applications. For high current applications see 33180 PhidgetInterfaceKit 0/0/4.

The relays are Single Pole Double Throw (SPDT).

Specifications:

  • Maximum DC Switching Voltage: 220VDC
  • Maximum DC Switching Current: 2 Amps
  • Maximum AC Switching Voltage: 250VAC
  • Maximum AC Switching Current: 2 Amps

Note: When a relay is in one switch position for a period of time, oxidation of the open contact(s) can occur. Depending upon the internal coating material of the contacts, oxide films of varying density will be displaced upon the surface of open contacts; this film acts as an insulator to current flow. When the relay is switched, a certain amount of current flowing through the contacts, known as the wetting current, is required to remove the film of oxides and ensure proper conduction. The wetting current required to operate this relay is low enough for use in signal switching applications.

Comes packaged with a 180cm USB Cable, a Getting Started Manual, a mounting hardware kit, and a sheet of labels.
