SMTpads-Size3U, 160x100mm, 200x100mil, SMT Pad Protoboard

20954

$12.99

USD

Qty
Price
1
$12.99 ea.

These large 200x100mil pads suit larger SMD parts


Description [Hide]

If you're making your own circuits, you will come across the need for some surface-mount parts to be added to your design. Breadboard Prototyping Systems has made a series of boards that will make your task simpler!

These boards feature a square pad grid for 0402, 0603, 0805, 1206, and other SMT parts needing a ground plane.

Features:

  • 180x80mil (that's 0.080") rectangular pads on 100mil center spacing for convenient large SMT device mounting.
  • Solid ground plane on reverse side provides easy ground connections for noise supression.
  • Unplated holes to the ground plane are spaced 2 pads apart for easy connection to the ground plane. Just insert a wire and solder both sides.
  • Lead free etched copper PCB with an anti- tarnish coating to preserve solderability.
  • Bridge pads or solder wires on pads to create traces wherever they are needed.

Specifications:

  • 160 x 100 x 1.6mm (6.3 x 3.94 x 1/16").
  • 128 x 62 pad array
  • High quality etched FR4 glass-epoxy circuit board. 1oz/ft2 copper.
  • Lead free copper PCB with an antitarnish coating for easy soldering. RoHS compliant.
  • Array of 0.79mm (0.031") holes for connections to ground plane.
