1-element Addressable WS2812B LED Circle

60589

1.25 USD
Qty
Price
1
$1.25 ea.

This is a single element Addressable LED Board


Description [Hide]

This LED Ring is a small chainable board with 1 WS2812 RGB LED. The WS2812 LEDs are addressable as the driver chip is located inside the LED. Each LED has ~18mA constant current drive so the color will be very consistent even if the voltage varies, and requires 5V. Each board is equipped with a single data line with a very timing-specific protocol requiring a real-time microcontroller with a 8MHz or faster processor such as an AVR, Arduino, PIC, mbed, etc. There are solder pads on the back for connecting wires.

Specifications:
  • Number of LEDs: 1
  • Maximum Current per LED: 50 mA
  • Element: WS2814B
  • Data Speed: 800Khz
  • Dimensions: 14mm Diameter x 3.2mm



See also:

8-element  Addressable WS2812B LED Ring

12-element  Addressable WS2812B LED Ring

16-element  Addressable WS2812B LED Ring

24-element  Addressable WS2812B LED Ring
