Phidgets Precision Temperature Sensor

33440

$14.55

USD

Qty
Price
1
$14.55 ea.

Temperature sensor with a range of -30°C to +80°C with a typical error of ±0.75°C in the 0°C to 80°C range.


Description [Hide]

Product Features

  • Measures ambient temperatures from -30°C to +80°C
  • Typical error: ±0.5°C
  • The sensor is Ratiometric.

Note: The temperature sensor component is rated at -50°C to +150°C, but the other components on the board, the connector and the cable are rated at -30°C to +80°C. In a fast prototyping environment the temperature sensor board can be pushed to the ratings of the sensor component, but you should use the lower temperature ratings if you plan to use the 33440 in a commercial application.

If you need to measure temperatures outside the -30 to +80C range, you should use a PhidgetTemperatureSensor Thermocouple 1-Input with the appropriate temperature probe.

Comes with a 60cm sensor cable.

This sensor requires connection to an Analog Input on a Phidget Interface board, like the 8/8/8.

Product Specifications

Current Consumption 1mA
Minimum Measurable Temperature -30°C
Maximum Measurable Temperature +80°C
Voltage Output Range at Nominal 5V Supply 0.25VDC to 4.75VDC
Device Supply Operating Range 4.0VDC to 6.5VDC
Typical Error @ 25°C ±0.5°C
Typical Error over 0°C to 80°C ±0.8°C
Maximum Error over 0°C to 80°C ±2°C

 Comparison Table

Product

Plugs into

No of Inputs

Uses Probe

Temp Range

TemperatureSensor Thermocouple 1-Input

Computer

 1

 Yes

 -200 to +1250°C

Precision Temperature Sensor

 InterfaceKit

 1

 No

 -30 to +80°C

Humidity/Temperature Sensor

 InterfaceKit

 1

 No

 -30 to +80°C
