MOP-AL162A-BYFY

18700

$12.95

USD

Qty
Price
1
$12.95 ea.

The MOP-AL162A-BYFY lets your microcontroller display data on a screen of 2 lines x 16 characters per line.


Description [Hide]

Sometimes the classics are best. The MOP-AL162A-BYFY is a simple, clean and clear, standard green display that adds professionalism and cleanliness to any embedded project. This display is a high quality parallel, 2x16 (2 row x 16 character), green back-lit LCD display that features an industry standard Hitachi HD44780 4/8 bit compatible controller that works with any embedded processor.

Specifications:

Display Info:

  • Interface: HD44780 4/8 bit compatible
  • Display: Liquid Crystal
  • Type: Alphanumeric
  • Size: 16 Character x 2 Row
  • Color: Green
  • Back Light: White
  • Polarizer: Transmissive


Mechanical Information:

  • Module Size: 80.00 mm(length) x 36.00 mm(width) x 14.00 mm(thickness)
  • Character Size: 5.55 mm(length) x 2.95 mm (width)
  • Display Size: 64.50 mm(length) x 15.50 mm(width)


Electrical Information:

  • Input Voltage: 5V
  • Display Current: 10 mA
  • Back Light Current: 150 mA

Documentation [Hide]
