ATtiny2313 Target Board

13125

$4.75 USD
Qty
Price
1
$4.75 ea.

Simple target boards for ATtiny2313 microcontrollers and mini-development kits.


Description [Hide]

Low cost and convenient target/breakout boards for Atmel ATtiny2313 AVR microcontrollers.

Upgraded! Now shipping version 1.1 of the 'tiny2313 circuit board!

'tiny2313 Target Board specs:

  • Overall size 2" x 3.5" (Standard business card size)
  • Thickness: 0.031", i.e., 1/32" or 0.8 mm. (Half of standard circuit board thickness.) That's thick for a business card-- like some of the superpremium embossed cardstock ones, but it is pretty thin for a circuit board. It's just thick enough to be reasonably rigid.
  • Lead-free (RoHS compliant) construction
  • Single-sided PCB design
  • Easy to solder lead-free finish
  • FR-4 fiberglass-epoxy board material; UL94V-0 rated
  • Black solder mask with white silkscreen on both sides


'tiny2313 Target Board features:

  • Fits Atmel ATtiny2313 microcontrollers
  • Individual labels for all pins of the microcontroller
  • Four extra access holes connected to every pin of the microcontroller
  • Compatible with 20-pin ZIF DIP sockets
  • Prototyping areas: 28 independent sets of four connected plated through holes; fits two DIP-8 packages.
  • Multiple access points for power and ground.
  • Power jack location to connect to a 3-5 V DC power adapter
  • 6-32 clearance mounting holes provided at each corner
  • Accommodates 3-pin ceramic resonator or crystal oscillator with capacitors

Go here for more information about this circuit board and its design.
