Engineer's Mini Notebook (VOL 1)




$12.95 ea.

Volume I of the Forrest Mims Engineer's Mini Notebook series includes three of his best-selling notebooks: 555 Timer IC Circuits; OP-Amp Projects; and Optoelectronics.

Description [Hide]

This Engineer's Mini Notebook features more that two dozen 555 timer circuits that you can build, including tone generators, LED flashers, sound effect circuits, and a touch switch. It also includes more than 50 operational amplifier (Op-Amp) circuits, many with simple formulas to help you modify them for special circuits of your own design. A wide range of optoelectronic circuits and projects are featured, including many LED circuits and various lightwave communications systems.

Build These Projects:

  • Sound Effects Generator
  • Tone Burster
  • Chirp Generator
  • Gated Oscillator
  • Pulse Generator
  • Frequency Meter
  • LED FLasher
  • Audio Amplifier
  • Sound Meter
  • Percussion Synthesizer
  • Photophone
  • Light Sensitive Circuits
  • And Many More

124 Pages 5.25" x 8.25" Softcover

Also available as a set of 4 Volumes (Engineer's Mini Notebook Compendium)
